Cage Focus Stage
C30-FS
C30-FS enables fine adjustment in the optical axis direction while assembling an objective lens adapter or a cross motion holder.
| Name | Cage Focus Stage |
|---|---|
| Weight | 0.1680kgs |
| Guide |
▶Please contact our Sales for methods to fix the cage system to other equipment and parts not included in the WEB catalog. ▶For consultation of optical system using cage system please contact Sales. |
| Attention |
▶If the rod is tightened too tightly or if the tightening force is greatly different depending on the location, the rod may not fit in other holders. ▶Initially fix the rod lightly, after building the optical system, please tighten so that the force that fixes the rod is even in each holder. ▶When configuring a large optical system or a long optical system, it may become distorted or become unstable due to vibration. |
| Travel | ±6.5mm |
| Guide Rod Diameter (Spaceing between rod) | φ6mm （30x30mm） |
| Stage Mounting Threads | M3 |
| Smallest Graduation of Micrometer | 10µm |
| Height, Cage Optical Axis to Stage Platform | 20mm |
In stock
SKU
C30-FS
$428.00
Customize product
C30-FS enables fine adjustment in the optical axis direction while assembling an objective lens adapter or a cross motion holder.
