Cage Iris Diaphragm Holders

C-IH-16

Cage Iris Diaphragm Holders
In stock
SKU
C-IH-16
◦ The cage system has two types, P30 (Dia. 6mm rods, 30mm pitch between the rods) and P16 (Dia. 4mm rods, 16mm pitch between the rods).
◦ The holder plate can slide through the rod (cage) in the direction of the optical axis. Even without using the stage, it can easily adjust focus on the lens and camera.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Delivery Price Add to cart
i
Cage Iris Diaphragm Holder
C16-IH-8
in stock
$97.00
Primary material Aluminum
Guide Rod Diameter (Spaceing between rod) φ4mm (16x16mm)
Aperture Diameter MIN φ0.7mm
Aperture Diameter MAX φ8mm
Installation Slots fit from the side of rods
