OEM Set-and-Lock Dovetail X Stages

TASB-1

OEM Set-and-Lock Dovetail X Stages
In stock
SKU
TASB-1
Preset dovetail translation stages with leadscrew actuators and locking mechanism. Ideal stages for system integration.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Stage Size Travel Load Capacity Delivery Price Add to cart
i
25X25mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-3mm, M2 Threads
TASB-251
25×25mm ±3mm 49N (5.0kg)
in stock
$103.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.5mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 2N・m
Max. Moment Capacity / Roll 2N・m
Max. Moment Capacity / Yaw 1.0N・m
Moment Stiffness / Pitch 2.0″/N・cm
Moment Stiffness / Roll 1.5″/N・cm
Parallelism 50μm
i
65X65mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-12.5mm, M6 Threads
TASB-651-M6
65×65mm ±12.5mm 147N (15.0kg)
in stock
$153.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.5mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 5.1N・m
Max. Moment Capacity / Roll 5.1N・m
Max. Moment Capacity / Yaw 4.0N・m
Moment Stiffness / Pitch 0.35″/N・cm
Moment Stiffness / Roll 0.35″/N・cm
Parallelism 50μm
i
40X40mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-7mm, 6-32 Threads
TASB-401UU
40×40mm ±7mm 98N (10.0kg)
in stock
$111.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.5mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 4.0N・m
Max. Moment Capacity / Roll 3.75N・m
Max. Moment Capacity / Yaw 3.0N・m
Moment Stiffness / Pitch 0.61″/N・cm
Moment Stiffness / Roll 0.51″/N・cm
Parallelism 50μm
i
65X65mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-12.5mm, 1/4-20 Threads
TASB-651UU
65×65mm ±12.5mm 147N (15.0kg)
in stock
$153.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.5mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 5.1N・m
Max. Moment Capacity / Roll 5.1N・m
Max. Moment Capacity / Yaw 4.0N・m
Moment Stiffness / Pitch 0.35″/N・cm
Moment Stiffness / Roll 0.35″/N・cm
Parallelism 50μm
i
15X15mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-2mm, M2 Threads
TASB-151
15×15mm ±2mm 9.8N (1.0kg)
in stock
$97.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.4mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 0.5N・m
Max. Moment Capacity / Roll 0.5N・m
Max. Moment Capacity / Yaw 0.2N・m
Moment Stiffness / Pitch 8.0″/N・cm
Moment Stiffness / Roll 7.0″/N・cm
Parallelism 50μm
i
60X60mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-10mm, M4 Threads
TASB-601
60×60mm 10mm 147N (15.0kg)
2 weeks
$139.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.5mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 5.1N・m
Max. Moment Capacity / Roll 5.1N・m
Max. Moment Capacity / Yaw 4.0N・m
Moment Stiffness / Pitch 0.4″/N・cm
Moment Stiffness / Roll 0.3″/N・cm
Parallelism 50μm
i
40X40mm Dovetail Bearing, Brass, X-Axis Stage, Center Leadscrew, +/-7mm, M3 Threads
TASB-401
40×40mm ±7mm 98N (10.0kg)
in stock
$111.00
Guide Method Dovetail method
Primary Material Brass
Finish Black matte
Screw Pitch 0.5mm
Travel Accuracy / Straightness 10μm
Max. Moment Capacity / Pitch 4.0N・m
Max. Moment Capacity / Roll 3.75N・m
Max. Moment Capacity / Yaw 3.0N・m
Moment Stiffness / Pitch 0.61″/N・cm
Moment Stiffness / Roll 0.51″/N・cm
Parallelism 50μm

You must be logged in to ask questions

Ideal for system integration where fine alignment is made, the stage is locked, and the system is sealed or closed.
Multiple square footprints available.
Minimal protrusions, including the adjustment knob, to fit within tight locations.
Lockable with the use of a small locking set screw and wrench.
