Crossed-Roller Aluminum XZ Stages

TAM-4L

More about
Crossed-Roller Aluminum XZ Stages
In stock
SKU
TAM-4L
These XZ assemblies incorporate an (X) axis aluminum linear stage and a (Z) axis aluminum stage with an integrated vertical bracket.
Crossed roller guides enable smooth travel.
Add to Wish List
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Stage Size Travel Load Capacity Delivery Price Add to cart
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads
TAM-804SL 		80×80mm X axis : ±7.5mm Z axis : ±7.5mm 49N (5.0kg)
6-12 weeks
$893.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads with Fine Pitch Screw
TAM-404SLFP 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$608.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads with Fine Pitch Screw
TAM-404SLFPUU 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$608.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads with Fine Pitch Screw
TAM-604SLFP 		60×60mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$702.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads with Fine Pitch Screw
TAM-654SLFP-M6 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$774.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads with Fine Pitch Screw
TAM-654SLFPUU 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$774.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads with Fine Pitch Screw
TAM-804SLFP 		80×80mm X axis : ±7.5mm Z axis : ±7.5mm 49N (5.0kg)
6-12 weeks
$821.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads Right Hand
TAM-404SRL 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$679.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads Right Hand
TAM-404SRLUU 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$679.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads Right Hand
TAM-604SRL 		60×60mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads Right Hand
TAM-654SRL-M6 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$845.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads Right Hand
TAM-654SRLUU 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$845.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads Right Hand with Fine Pitch Screw
TAM-404SRLFP 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$608.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads Right Hand with Fine Pitch Screw
TAM-404SRLFPUU 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$608.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads Right Hand with Fine Pitch Screw
TAM-604SRLFP 		60×60mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$702.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads Right Hand with Fine Pitch Screw
TAM-654SRLFP-M6 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads Right Hand with Fine Pitch Screw
TAM-654SRLFPUU 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Side
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads
TAM-404CL 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
in stock
$679.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Inch Threads
TAM-404CLUU 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$679.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads
TAM-604CL 		60×60mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads
TAM-654CL-M6 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
in stock
$845.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Inch Threads
TAM-654CLUU 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
in stock
$845.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads
TAM-804CL 		80×80mm X axis : ±7.5mm Z axis : ±7.5mm 49N (5.0kg)
2-3 weeks
$893.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads with Fine Pitch Screw
TAM-404CLFP 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$608.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Inch Threads with Fine Pitch Screw
TAM-404CLFPUU 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
6-12 weeks
$608.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads with Fine Pitch Screw
TAM-604CLFP 		60×60mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$702.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads with Fine Pitch Screw
TAM-654CLFP-M6 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Inch Threads with Fine Pitch Screw
TAM-654CLFPUU 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Center Drive Metric Threads with Fine Pitch Screw
TAM-804CLFP 		80×80mm X axis : ±7.5mm Z axis : ±7.5mm 49N (5.0kg)
2-3 weeks
$821.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads
TAM-404SL 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$679.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads
TAM-404SLUU 		40×40mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
in stock
$679.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads
TAM-604SL 		60×60mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
2-3 weeks
$774.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Metric Threads
TAM-654SL-M6 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
in stock
$845.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)
i
Aluminum Crossed Roller XZ Stage Side Drive Inch Threads
TAM-654SLUU 		65×65mm X axis±6.5mm　Z axis±6.5mm 49N (5.0kg)
in stock
$845.00
Micrometer Position Side
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
Load Capacity 49N(5.0kgf)

You must be logged in to ask questions

These XZ assemblies incorporate an (X) axis aluminum linear stage and a (Z) axis aluminum stage with an integrated vertical bracket.
Crossed roller guides enable smooth travel.
