CageCore Iris Holder

C30-CU-IH

CageCore Iris Holder
In stock
SKU
C30-CU-IH
A diaphragm holder that can be shared with 30mmCage system and core unit.
custom product
Customize product
Filters
Enabled filters :
Remove all filters

Attention ▶If the rod is tightened too tightly or if the tightening force is greatly different depending on the location, the rod may not fit in other holders.
▶Initially fix the rod lightly, after building the optical system, please tighten so that the force that fixes the rod is even in each holder.
▶When configuring a large optical system or a long optical system, it may become distorted or become unstable due to vibration.

Name Delivery Price Add to cart
i
CageCore Iris Holder
C30-CU-IH-15
3-5 days
€179.80
Primary material Aluminum
Guide Rod Diameter (Spaceing between rod) φ6mm (30x30mm)
Aperture Diameter MIN φ0.9mm
Aperture Diameter MAX φ15mm
